Configuration

Extron Comm Adapters

Setting the System 8/10 P
______ Do not change any switch settings without following the correct procedure in this
Triple-Action Switching™ (RGB Delay Switch - RS5)
www.camboard.de
Extron • System 8/10 P
LUS
CAMBOARD Electronics
Extron communications adapters (Comm Adapters) provide the interface
between the 9-pin connector of the communications cable and the display's
switcher port. Extron manufactures a wide range of Comm Adapters to interface
with virtually all projector makes and models. Your Extron representative will help
you select the correct Extron Comm Adapter to meet your specific projector
requirements.
for the Projector
LUS
Before each System 8/10 P
requested by the user. However, it can easily be reconfigured for any application.
The picture below shows the function of each switch behind the access cover on
the front panel of the System 8/10 P
chapter. Go to the appropriate procedure for your application.
When an input is selected, the sync switches immediately. However, the picture
may be switched later (0.0 - 7.5 seconds) to prevent an unstable image while the
projector is setting up for the new sync signal. RS5 is used to set this delay.
Each position of the switch adds 0.5 seconds to the delay.
Tel. 07131 911201
• User's Manual
Fax 07131 911203
Projector/Monitor Installation
ships, it is configured for the projector type as
LUS
.
LUS
ce-info@camboard.de
3-4
