Changing the Host Baud Rate

_____ Do NOT touch any switches or electronic components, other than SW3 and
www.camboard.de
Extron • System 8/10 P
LUS
CAMBOARD Electronics
Switch 4: When set "ON" - if the front panel's Display Power button is
momentarily depressed, the connected projector will immediately
power up/down without the default 2-second delay.
When set "OFF" - the front panel's Display Power button must be
depressed for 2 seconds before the connected projector will
power up/down.
Use the procedure on page B-3 to remove the System 8/10 P
ON
OFF
59 ,125MEJ?DAI
1. With the cover removed, locate the Host Baud Rate switch SW3.
switches 3 or 4 of SW1 - see previous page. This could seriously affect the
operation of the switcher.
The factory setting for SW3 is 5 (9600 baud, 8-bit, no parity and 1 stop bit).
Other SW3 settings are listed below.
For 8-bit, no parity, 1 stop bit:
Position 0 = 300 baud
Position 1 = 600 baud
Position 2 = 1200 baud
Position 3 = 2400 baud
Position 4 = 4800 baud
Position 5 = 9600 baud
Position 6 = 19200 baud
Position 7 = 38400 baud
2. Use a small screwdriver to rotate the switch to the position for the desired Host
baud rate.
3. When finished, replace the System 8/10 P
System 8/10 P to normal operation.
LUS
Tel. 07131 911201
• User's Manual
Fax 07131 911203
1 2 3 4 5
OPEN
For 8-bit, odd parity, 1 stop bit:
Position 8 = 300 baud
Position 9 = 600 baud
Position A = 1200 baud
Position B = 2400 baud
Position C = 4800 baud
Position D = 9600 baud
Position E = 19200 baud
Position F = 38400 baud
cover (page B-3) and return the
