- Page 1 UNDERGROUND OPERATOR 1 19AU 03 EN FOR SWING GATES Installation manual FROG MD - FROG MS English...
- Page 2 WARNING! important safety instructions: READ CAREFULLY! • REMISE PREVENT POTENTIALLY HAZARDOUS SITUATIONS EAD THE INSTRUCTIONS IF THE POWER • E MPLOY THIS PRODUCT ONLY FOR THE USE FOR WHICH IT WAS EXPRESSLY MADE SUPPLY CABLE IS DAMAGED IT MUST BE REPLACED BY THE MANUFACTURER OR AUTHORIZED .A.
-
Page 3: Gearmotor
ARE IN MILLIMETERS DESCRIPTION This product has been designed and built by CAME S.p.A. in compliance with applicable safety standards. The operator is composed of a foundation box, a gearmotor and a series of arms. The foundation box is made of steel that is 4 mm thick. Inside, there is the gearmotor, consisting of a die cast aluminium gearbox casing with an irreversible worm screw and spiral ring gear system inside, lubricated with SINCAT oil and fitted with a transmission arm. -
Page 4: Table Of Contents
Description of the components 1. Tie rod 2. Motor arm 3. Gearmotor 4. Cover 5. Foundation box 6. Upper arm 7. Arm unit 8. Brass 9. Casing hole cover 10. Mechanical stop 11. Limit switch Dimensions ~ 850... - Page 5 GENERAL INSTALLATION INSTRUCTIONS Installation must be carried out by qualified and experienced personnel in compliance with applicable regulations. ⚠ Preliminary checks Before installing the operator: ⚠ • Provide a suitable single-pole disconnection device, with a maximum of 3 mm between the contacts, to disconnect the power supply; •...
- Page 6 Example of a system 1. Right-hand gearmotor with foundation box 2. Left-hand gearmotor with foundation box 3. Junction box 4. Control panel 5. Antenna 6. Flashing light 7. Key selector 8. Photocells 9. Inspection chamber 10. Drainage chamber 11. Mechanical stops INSTALLATION The following illustrations are only examples, given that the space for securing the operator and accessories varies depending on the overall dimensions.
-
Page 7: Upper Arm
Installing the foundation box Before placing the casing, choose in which direction the leaf will open. Lean the box against the pillar making sure that the corrugated pipes and the drain pipe pass through the designated holes. Fill the hole with concrete. Position the box level with the ground and place the pin in line with the upper gate hinge. - Page 8 Install the gate leaf, inserting the upper hinge. Check that the leaf opens and closes without difficulty. Secure using suitable screws or weld the leaf carefully to the upper arm. Securing the gearmotor N.B. the figures below are shown from the outside to make the stages of assembling the right-hand gearmotor more intuitive. Insert the gearmotor in the foundation box and secure with nuts using the crow's-foot spanner supplied and a ratchet wrench (not supplied).
- Page 9 Secure the tie rod between the motor arm and the arm unit in the prepared holes using nuts and bolts. UNI 7474 M12 UNI 5739 M12x80 UNI 5739 M20x50 N.B. the arms have several holes in order to obtain various opening angles for the leaves. 90°...
-
Page 10: Mechanical Stop
Adjusting the mechanical stop Before determining the end run points, release the gearmotor, close the leaf manually and adjust the mechanical stop, bringing it to the end of its run with the motor arm. Secure the nuts. Motor arm Mechanical stop Establishing the limit-switch points For opening: - completely open the leaves;... - Page 11 ELECTRICAL CONNECTIONS Three-phase 400 V power supply R S T N OP.SENS. OP.SENS. OP.SENS. ZM3ES control panel U W V X W Y E BROWN BLACK Three-phase 400 VAC - BLUE 50/60 Hz power supply Star connection Delayed closing gearmotor connection Delayed opening gearmotor connection Three-phase 230 V power supply R S T N...
- Page 12 1) Connecting the open end run to the delayed 3) Connecting the close end run to the opening gearmotor. delayed closing gearmotor. 2) Connecting the close end run to the delayed 4) Connecting the open 2 FA1FC1FA2FC2 opening gearmotor. end run to the delayed closing gearmotor.
- Page 13 INSTALLING AND CONNECTIONS FOR OUTWARD-OPENINGS Below are the only procedures that vary compared to standard installations: N.B. the arms have several holes in order to obtain various opening angles for the leaves. 90° OPENING 95° OPENING ⬆ ⬆ Establishing the limit-switch points For opening: - completely open the leaves;...
- Page 14 MAINTENANCE ☞ Before any maintenance, disconnect power to prevent any possible dangerous situations that can be caused by accidental movement of the operator. Lubricate the pivot points with grease whenever abnormal vibrations or squeaking occurs, as shown below. Periodic maintenance Periodic maintenance log to be completed by the user (every six months) Date Notes...
- Page 15 ☞ CAME S.p.A. implements an EN ISO 14001 certified and compliant Environmental Management System at its plants, to ensure environmental protection. Please continue our efforts to protect the environment, something that CAME considers to be one of the foundations in developing its business and market strategies,...
- Page 16 HR • Za sve dodatne informacije o poduzeću, proizvodima i tehničkoj podršci na vašem jeziku: UK • Для отримання будь-якої іншої інформації про компанію, продукцію та технічну підтримку: www. came.com www. came.com CAME Cancelli Automatici S.p.A. CAME Cancelli Automatici S.p.A. Via Martiri Della Libertà, 15 31030 Dosson Di Casier...
