- Page 1 UNDERGROUND OPERATOR 119AS45EN FOR SWING GATES Installation manual FROG-A / FROG-AV / FROG-AE English...
-
Page 2: Read Carefully
• Keep away from the hinges and any moving mechanical parts • Stay out other use is therefore improper and dangerous. CAME Cancelli Automatici of the operating range of the operator while it is moving • Do not oppose the movement of the operator as this may result in danger •... - Page 3 ☞ This symbol tells you what to say to the end users. REGULATORY REFERENCES Came Cancelli Automatici is a company with an ISO 9001-certified company quality management system and an ISO 14001-certified environmental management system. The product complies with the regulations referred to in the declaration of conformity.
-
Page 4: Description Of The Components
Description of the components 1. Gearmotor 2. Transmission lever 3. Gearmotor arm 4. Limit switch adjusting screw when closing 5. Couple release lever 6. Mounting bracket to gate 7. Limit switch adjusting screw when closing 8. Foundation box 9. Casing hole 10. -
Page 5: General Installation Instructions
Dimensions (mm) GENERAL INSTALLATION INSTRUCTIONS Installation must be carried out by qualified and experienced personnel in compliance with applicable regulations. Preliminary checks Before installing the operator: • Provide a suitable single-pole disconnection device, with a maximum of 3 mm between the contacts, to disconnect the power supply; •... -
Page 6: Installation
INSTALLATION The following illustrations are only examples, given that the space for securing the operator and accessories varies depending on the overall dimensions. The installation technician is responsible for choosing the most suitable solution. the figures below illustrate the installation of the right-hand foundation box. Laying the corrugated pipes and inspection chambers Make the hole for the box. - Page 7 figure direction: internal right side view. Lubricate the foundation case pin, the latch and the gate bracket pin. Install the gate leaf, inserting the upper hinge. Check that the leaf opens and closes without difficulty. Carefully fix or weld the door to the gate fixing bracket. Securing the release It is important to lubricate the release tab;...
-
Page 8: Left Side
Securing the gearmotor Fit the adjusting screw into the motor arm. The direction in which the screw must be installed depends on the position of the operator. LEFT SIDE RIGHT SIDE VIEWED FROM INSIDE Open the leaf to simplify gearmotor installation and securing inside the foundation case. Use studs and nuts (supplied). -
Page 9: Electrical Connections
- loosen the adjusting screw (1) until it makes contact with the transmission lever (2); - tighten the nut (3) to lock the screw into position. ELECTRICAL CONNECTIONS For electrical connection operations follow the information in the control panel technical documents. Gearmotor Control panel FROG-A ZA3N - ZM3E FROG-AV ZA3N - ZM3E FROG-AE ZM3E... -
Page 10: Maintenance
Leaf manual release Insert the key/lever into the release lock and turn it counter-clockwise. Open the leaf until reaching end run To relock the door, return it to its closed position. MAINTENANCE ☞ Before any maintenance, disconnect power to prevent any possible dangerous situations that can be caused by accidental movement of the operator. Lubricate the pivot points with grease whenever abnormal vibrations or squeaking occurs, as shown in the figure. -
Page 11: Troubleshooting
☞ CAME CANCELLI AUTOMATICI S.p.A. implements an EN ISO 14001-certified and compliant Environmental Management System at its plants, to ensure environmental protection. Please continue our efforts to protect the environment, something that CAME considers to be one of the foundations in developing its business and market strategies, simply by observing brief recommendations as regards disposal: DISPOSAL OF PACKAGING Packaging components (cardboard, plastic, etc.) can be disposed of together with normal household waste without any difficulty, by simply separating the... - Page 12 HR • Za sve dodatne informacije o poduzeću, proizvodima i tehničkoj podršci: UK • Для отримання будь-якої іншої інформації про компанію, продукцію та технічну підтримку: www. came.com www. came.com CAME Cancelli Automatici S.p.a. CAME Cancelli Automatici S.p.a. Via Martiri Della Libertà, 15 31030 Dosson Di Casier...
