PHASE RESEARCH
USER GUIDE

SECTION 14 - DIAGNOSTICS SCREENS

14-1 Diagnostics

The Diagnostic screen is a monitoring feature that lets you view the number of operating excep-
tions FT (Fast Track) Events and Pullouts
–
From MENU Screen (see "Menu" on page 8-1):
1. Press
2. Press
3. Press the numbered pink keys (0 - 9) to enter your six-digit Access Code. You are now
in the Diagnostic screen, and the cursor is on the month in the date field.
4. Press
5. Press
SECTION 14 - DIAGNOSTICS SCREENS
THIS FEATURE REQUIRES AN ACCESS CODE FOR ENTRY
to move cursor to [DIAGNOSTICS].
. You are now prompted to enter your Access Code.
1 1 : 0 0 A M
D I A G N O S T I C
D A T E : F E B / 2 3 / 0 1
V I E W < > P R I N T
F T E V E N T S
P U L L O U T S
< A R R O W S >
< + o r - >
< E N T E R >
< M A I N M E N U >
to select the desired date.
to move cursor to [VIEW] or [PRINT].
for a particular day of operation.
–
M O N F E B
=
=
T O M O V E
T O S E T D A T E
T O C O N T I N U E
T O E X I T
2 3
14-1
