PHASE RESEARCH
USER GUIDE
Pressing <KEYBOARD MODE> makes the keys with pink triangles act as a telephone-style
Keypad, allowing you to enter characters and digits. Press the appropriate key from 0 through 9
one or more times to select the character you want to enter. Repeatedly pressing the keys cycles
through four alphanumeric characters, including the number in the pink triangle. For example,
the "2" key can be used to cycle through the characters "ABC2" (see below). After cycling to
the desired character, press <KEYBOARD MODE> to move to the next typing position to the
right. If you need to move left, up, or down on the screen, use the arrow keys after pressing
<DISPLAY MODE>.
NOTE: LETTER DESIGNATIONS ARE FOR REFERENCE ONLY.
SECTION 2 - OPERATION
ENTER
MAIN
MENU SELECT
DISPLAY
GHI
MODE
KEYBOARD
PRS
MODE
CLEAR
LETTERS DO NOT APPEAR ON KEYS.
ABC DEF
JKL MNO
TUV
A/B/
QZ
A+B
2-8
