LED Status Lights

The eight LED Status Lights on the Main Console show how customers are moving through
your drive-thru system. Labeled L1 through L8, these lights are activated when their corre-
sponding stations are active or occupied.
The pattern of the L1...L8 indicator lights on the Console lets you see at a glance where the cars
are in your drive-thru lanes. They also help you make sure that the Timer and its sensors are
working together properly.
Below is an example of what the LED Status Lights might indicate in a store with two drive-
thru lanes ("A" and "B") and four monitored stations in each lane.
SECTION 2 - OPERATION
SECTION 2 - OPERATION
MAIN ENTER PRINT
MENU SELECT DISPLAY
VIEW VIEW
DISPLAY
PERIODS TARGET
MODE
TIMES
KEYBOARD
MODE
CLEAR
L1 TO L8 layout.wmf
Vehicle
being Greeted at
Present at A
Side MENU
Board
L5
B SIDE MENU BOARD
L6
B SIDE GREET
L7
B SIDE
CASHIER
WINDOW
L1
A SIDE
MENU BOARD
L2
L3
A SIDE GREET
A SIDE
CASHIER
WINDOW
A/B/
A+B
Vehicle
Customer
Present at A
Side Win1 (Cashier)
A side
Menu Board
Note: L5 - L8 indicate presence/greeting for B side lane of a
dual lane Drive-Thru (e.g. L8 indicates a vehicle present at B
side Win2)
L8
B SIDE
PICK-UP
WINDOW
L4
A SIDE
PICK-UP
WINDOW
Vehicle
Present at A
Side Win2
(Service)
EXIT
EXIT
