The switch pedal(s) have no effect.
-
If you want to control Rotary speed check that the cable is properly connected to the [ROTARY] port.
-
If you want to use the Hold function (Sustain) check that the pedal cable is connected to the [HOLD]
connector.
-
Check if the connection cable is damaged.
The pedal(s) work in reverse.
-
Make sure your pedal(s) belong to the Normally Open (N.O.) type.
One or more of the following controls / effects do not seem to work.
-
Pedals: Assigned to the [PEDALS] output of the rear panel (see section 2 of section 3.2).
-
Pedals: If you play with the keyboard, check that the LED of the [PEDALS TO LOWER] button is lit.
-
Rotary: Excluded from the [LEFT], [RIGHT] and [PHONES] audio outputs (see section 23 of section 3.1).
