User Manual
CANCEL FUNCTION
While holding down the [TRANSPOSE SELECT] button and pressing [SET A/SET B], the LED lights red, the
Cancel function is activated, i.e. the Local Off of the instrument, through which it is possible to disable the
internal sound generation and allowing you to use the instrument as a master keyboard. In this mode, the
keyboard is sensitive to the strenght applied to the keys, so that notes transmitted by the [MIDI OUT 1] and
[MIDI OUT 2] ports will have variable velocity.
Press [SET A/SET B] again to return to the internal sound generation.
4.2 WHAT ARE PRESETS AND HOW TO USE THEM
The most famous electromechanic organs were also equipped with drawbars combinations through which
factory Presets could be used, without the need to manually change the position of the drawbars. These
combinations, which back then could not be modified by the user, were called Presets.
The Legend Solo features four Presets for the Upper section and four other Presets for the Lower sections.
These Presets can be recalled with the [UPPER PRESETS] and [LOWER PRESETS] buttons on the front panel
(see section 13 and 17 of section 3.1).
As in the original organs, the pedalboard has no Preset.
Upper section
Presets
EDITING AND SAVING PRESETS
To edit and store a Preset, follow these steps:
1. Select the Set A or Set B whose Preset you wish to edit (to select the Set, use the [SET A/SET B] button as
described at point 5 of par. 3.1).
2. While holding down the [TRANSPOSE SELECT] button, press the [UPPER PRESET 1] button if you want to
store a Preset in the Upper section or [LOWER PRESET 1] for Presets in the Lower section. The leds start
to blink, indicating that the instrument is ready to save a Preset.
3. While holding down [TRANSPOSE SELECT], press the Preset button you want to edit and store.
4. Release [TRANSPOSE SELECT].
FACTORY RESET
Once a Preset is saved, the previous drawbar configuration contained therein is lost. To restore it, perform a
factory reset, which resets ALL Presets to the original factory configuration. To do this, turn the instrument on
with the [LOWER PRESET 1], [LOWER PRESET 2] and [ROTARY CLASSIC/ROCK] buttons pressed, then
release them after all the side panel LEDs have blinked four times.
NB
When a Factory Reset is performed, all the user-edited Presets will be irreparably lost.
viscount
EN - 12
Lower section
Presets
