INSTALLATION REQUIREMENTS

INSTALLATION CLEARANCES

When selecting the installation location for the Cobalt
Gas Heater, the following minimum clearances to
combustible materials must be followed.
Additional clearance may be required for glass, painted
surfaces or other materials which may be damaged by
radiant or convection heat. It is the installers responsibility
to ensure that adjacent materials are not subject to
degradation.
Fire Sprinklers must be located at an appropriate distance
from each heater to avoid accidental activation of the
sprinkler. Ethylene glycol or propylene glycol must never be
used in fire sprinkler systems where heaters are present as
these substances may become flammable when heated. A
fire sprinkler professional must be consulted when heaters
are installed where fire sprinklers are present to insure that
heaters and the fire sprinkler system are properly integrated.
Specific guidelines can be found in NFPA 13 regarding
design and specifications for Fire Sprinkler Systems near
heaters.
Ceiling Mount Face Down
24"
Ceiling Mount Face Down
17"
Wall Mount Face Down
16"
www.bromic.com/heating
CONTINUED...
Care should be taken to ensure that the heater is not
installed:
• Where heat/ignition can cause damage to gas
cylinders/lines
• Near combustible materials
• In open locations subject to rain
• In areas without sufficient clearances (refer below)
Note: Heater should be installed in such a way so as to
allow adequate;
• Clearance around air openings to combustion
chamber
• Clearance from combustible material
• Provisions for accessibility and clearance for
combustion and ventilating air supply.
WARNING
Certain materials or items, when stored under or near
the appliance, will be subjected to radiant heat and
could be seriously damaged.
Clearance to combustible materials in front of the heater
must be a minimum of 48".
Ceiling Mount Face Angled
Wall Mount Angled
10"
8"
7
