COBALT GAS HEATER
BY BROMIC
INSTALLATION, INSTRUCTION AND
SERVICE MANUAL
SUITABLE FOR GAS RADIANT HEATER MODELS:
COBALT GAS HEATER
If you smell gas:
1.
Shut off gas to the appliance
2.
Extinguish any open flame
3.
If odor continues, keep away from the
appliance and immediately call your gas
supplier or fire department
WARNING:
For either indoor or outdoor installation.
NOT FOR USE IN RESIDENTIAL DWELLINGS
Version 2.1 USA - CANADIAN
DANGER
WARNING
Do not store or use gasoline or other flammable
vapor and liquids in the vicinity of this or any
other appliance.
An LP-cylinder not connected for use shall not be
stored in the vicinity of this or any other appliance.
WARNING: Improper installation,
adjustment, alteration, service or maintenance
can cause property damage, injury or death.
Read the installation, operating and
maintenance instructions thoroughly before
installing or servicing this equipment.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Cobalt and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Bromic Heating Cobalt

  • Page 1 COBALT GAS HEATER BY BROMIC INSTALLATION, INSTRUCTION AND SERVICE MANUAL SUITABLE FOR GAS RADIANT HEATER MODELS: COBALT GAS HEATER WARNING DANGER Do not store or use gasoline or other flammable If you smell gas: vapor and liquids in the vicinity of this or any other appliance.
  • Page 2 Note: Bromic Heating Pty Ltd reserves the right to make changes to specifications, parts, components and equipment without prior notification. This Installation, operation and service manual may not be reproduced in any form without prior written consent from Bromic Heating Pty Ltd.
  • Page 3: Table Of Contents

    CONTENTS IMPORTANT NOTES & WARNINGS PRODUCT OVERVIEW PRODUCT DESCRIPTION SPECIFICATIONS GENERAL INFORMATION PRODUCT FEATURES INSTALLATION REQUIREMENTS GAS REQUIREMENTS INSTALLATION CLEARANCES INSTALLATION INSTRUCTIONS HEATER INSTALLATION INSTRUCTIONS GAS SUPPLY INSTALLATION POWER SUPPLY INSTALLATION LEAKAGE TEST HEAT DEFLECTOR INSTALLATION INSTRUCTIONS CEILING MOUNT POLE INSTALLATION INSTRUCTIONS OPERATING INSTRUCTIONS TURNING THE APPLIANCE ON TURNING THE APPLIANCE OFF...
  • Page 4: Important Notes & Warnings

    IMPORTANT NOTES AND WARNINGS • Do not use the heater until all connections have been WARNING leak tested by an authorized person. • Inspect the hose assembly before each use of the • CHILDREN AND ADULTS SHOULD BE ALERTED TO appliance.
  • Page 5: Product Overview

    PRODUCT OVERVIEW PRODUCT DESCRIPTION The Cobalt Gas Heaters are designed to provide effective heating whilst offering an appealing design. The heaters incorporate full function electronic controls, allowing them to be operated remotely from a conveniently located switch. SPECIFICATIONS Manufactured by Bromic Heating Pty Ltd Approval No.
  • Page 6: General Information

    The MAX inlet pressure to the appliance is 14” W.C overhead cover and no more than two side walls. These side walls may be parallel, as in a breezeway, Cobalt Natural Gas Models: or at right angles to each other (ref. Appendix A, •...
  • Page 7: Installation Clearances

    INSTALLATION REQUIREMENTS CONTINUED... INSTALLATION CLEARANCES Care should be taken to ensure that the heater is not installed: When selecting the installation location for the Cobalt • Where heat/ignition can cause damage to gas Gas Heater, the following minimum clearances to cylinders/lines combustible materials must be followed.
  • Page 8: Installation Instructions

    WARNING Please see specifications for the weight of the Heater. The Heater must be mounted horizontal in the installer of the Cobalt Gas Heaters must comply with all lengthwise direction. relevant State Occupational Health & Safety Regulations. Heater must be mounted in a fixed position independent of gas and electrical supply lines.
  • Page 9 INSTALLATION INSTRUCTIONS CONTINUED... STEP 3: Ensure 2x screws are assembled to the bracket at the back of the heater. Bring heater up to the extension arm and hang the heater on the bracket by hooking the 2x screws into the mounting slots. Tighten the 2x screws to secure heater. STEP 4: Position the heater at correct angle for the selected mounting option.
  • Page 10: Gas Supply Installation

    1/2 psi (3.5kPa). Please Note: The appliance must be isolated from the gas supply piping Cobalt Gas Heaters do not have their own on/ system by closing its individual manual shutoff valve during off switch. Operation should be controlled via the any pressure testing of the gas supply piping system at test mains power.
  • Page 11 INSTALLATION INSTRUCTIONS CONTINUED... IMPORTANT IMPORTANT The gas hose & electrical supply cord must be kept away The gas hose & electrical supply cord must be from combustion gases of the heater. kept away from heater surfaces and mounting bracket. The below diagrams illustrate where combustion gasses exit the heater for each heater mounting position, and what When the heater is on the heater surfaces and positions the gas hose and electrical supply cord must exit...
  • Page 12: Operating Instructions

    This can be done by observing the EXTERIOR SERVICING red glow through the face. The exterior Cobalt Gas Heater head components are Note: A slight variation in colour is to be expected. constructed from stainless steel.
  • Page 13 WIRING DIAGRAM ELECTRICAL DIAGRAM SEE INSTRUCTION MANUAL FOR DETAILS ON HOW TO CONNECT THE ELECTRICAL COMPONENTS. Grand Mate Gas Valve Ignition & Ionisation Transformer Orange White 11 10 Control Note: If any of the original wire as supplied with the heater must be replaced, it must be replaced with 18AWG, 90ºC type UL approved wire or its equivalent.
  • Page 14 REPLACEMENT PARTS No. Description Part No. Mounting Bracket Set BHXXXXXXX Control Cover Plate BHXXXXXXX Control BHXXXXXXX Transformer BHXXXXXXX Gas Valve BHXXXXXXX Wiring Harness BHXXXXXXX Front Cover Set BHXXXXXXX Burner BHXXXXXXX Internal Gas Hose BHXXXXXXX www.bromic.com/heating...
  • Page 15: Troubleshooting

    TROUBLESHOOTING SYMPTOM POSSIBLE CAUSE CORRECTIVE ACTION 1. Have authorized electrician check 1. No power power supply Heater will not turn on 2. No gas 2. Have authorized gas fitter check gas supply 1. • Check and set gas pressure • Check and clear obstruction to 1.
  • Page 16 APPENDIX A www.bromic.com/heating...
  • Page 17 APPENDIX A CONTINUED... www.bromic.com/heating...
