7.3.2.2 Cable

7.3.2.3 Termination

7.3.2.4 Diagnostics

Any PROFIBUS DP-approved cables specified in the EN 50170 as ca-
ble type A can be used.
Parameter
Wave Impedance
Capacitance Per Unit
Length
Loop Impedance
Wire Diameter

Fig. 7-24: Cable characteristics PROFIBUS

The maximum line length depends on the baud rate used (DIN EN
19245 Part 3).
Baud Rate
187.5 kBit/s
500 kBit/s
1500 kBit/s
3000 to 12000 kBit/s

Fig. 7-25: Baud rate PROFIBUS

Terminate the PROFIBUS at both ends by terminating resistors. If you
are using special PROFIBUS connectors, these resistors are usually
integrated into the connector and can be connected.
A diagnostics LED is located on the rear of the small operator terminal.
The LED shows the states of the bus system.
The diagnostics LED on the small operator terminal has the following
function:
Color State Function
Green ON Communication Active

Fig. 7-26: Function of the PROFIBUS-DP diagnostics LED

Rexroth IndraControl VCP 05 | R911310377 / 02
Value
136 to 165 Ohm
< 30 pf/m
110 Ohm/km
0.64 mm (0.002")
Cable Length
1000 m (3280.839 feet)
400 m (1312.335 feet)
200 m (656.167 feet)
100 m (328.083 feet)
