R911310377 / 02 | Rexroth IndraControl VCP 05

Technical Data

4 Technical Data
4.1

Front Panel and Enclosure

Front Panel and Enclosure
Enclosure
Front Panel
Front Panel Cover
Seal
Mounting Cutout
Mounting Depth
Degrees of Protection
Total Weight
4.2

Keyboard

Keyboard
Type
Number of Keys
Key Area (Raised)
Actuator Travel
Actuating Force
Switching Cycles
Lifetime (Min.)
Display Elements
Electric Drives and Controls | Bosch Rexroth AG
Steel Sheet, Galvanized
Aluminum, anodized natural finish 168 mm x 120 mm x
5 mm (6.614" x 4.724" x 0.196") - (H x W x D)
Polyester Foil
Circumferential Rubber Seal on the Rear
160 mm x 112 mm (6.299" x 4.409") - (H x W)
About 55 mm (2.165")
Front: IP65
Rear: IP20
About 500 g
Membrane Keyboard
30
11 mm (0.433") - (H x W)
0.3 mm (0.011")
3 N
Approx. 3 millions under the following conditions:
Pressing Element: Test Plunger (DIN 42115)
Pressing Force: 10 N
Pressing Frequency: 1 Hz
2 Million Switching Cycles
9 Status LEDs
4-1
