Ordering Information

9 Ordering Information
9.1

Type Code

Abbrev.
Column 1 2 3 4
Example: V C P 0 5 . 2 D S N - 0 0 3 - N N - N N - P W
1. Product
1.1 VCP. . . . . . . . = VCP
2. Line
2.1 5. . . . . . . . . . . . . . . . . = 05
3. Design
3.1 2 . . . . . . . . . . . . . . . . . . . . . . = 2
4. Front panel and display
4.1 3", graphic display (160 x 80);
30 keys . . . . . . . . . . . . . . . . . . = DS
5. Upgrade option
5.1 none . . . . . . . . . . . . . . . . . . . . . . . . = N
6. Application memory
6.1 3 MB. . . . . . . . . . . . . . . . . . . . . . . . . . . . = 003
7. Interface
7.1 standard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . = NN
7.2 DeviceNet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . = DN
7.3 PROFIBUS-DP . . . . . . . . . . . . . . . . . . . . . . . . . . = PB
7.4 Serial (RS232/485) . . . . . . . . . . . . . . . . . . . . . . . = SR
8. Additional design
8.1 none. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . = NN
9. Firmware
9.1 with preloaded firmware
The small operator terminals are available in different variants. Type
code:
1
5 6 7 8 9 0 1 2 3 4 5 6 7 8 9
. . . . . . . . . . . . . . . . . . . . . . = PW
Fig. 9-1: Type code
