Installation, cont'd

Cabling

www.camboard.de
2-6 DDS 100 Installation
CAMBOARD Electronics
3. Place the rubber foot on one corner of the scaler as shown in figure 6,
and press it into place.
Position each rubber foot carefully before pressing it into place. It is
difficult to move a foot after it is in place.
0. 5A
Hz
/6 0
50
0- 24 0
10
Figure 6 — Installing the rubber feet
4. Repeat steps 2 and 3 to install a rubber foot on each of the remaining
corners of the scaler.
5. Turn the DDS 100 right side up and place it in the desired installation
location.
The scaler can connect to an input device, such as an interface that is
attached to a high-resolution workstation, and to an output device, such
as an LCD projector, LCD display, or plasma display. Refer to figure 7 as
you connect the devices.
Use the following information when attaching both input and output
cables to the scaler.
RGsB — If coax cables are connected and terminated (75 ohms) to
R G B H/HV V
RGBS — If coax cables are connected and terminated (75 ohms) to
R G B
H/HV V
RGBHV — If coax cables are connected and terminated (75 ohms)
R G B H/HV V
Tel. 07131 911201
Fax 07131 911203
-2 3 2
R S
T E
M O
R E
T
O U
V G A
H
H V
V
S O G
V
H /H
B
G
R
V
V
H /H
B
G
R
T /
P U O U T
IN
O P
L O
Rubber Feet
(4 Plcs) Bottom Side
the red, green, and blue channels only,
the format will be sync on green.
the R, G, B, and H/HV (composite sync)
channels, the format will be composite
sync.
to the R, G, B, H/HV, and V channels, the
format is separate horizontal and vertical
sync.
