INSTALLATION INSTRUCTIONS
VOLT
Traditions Path & Area Light
390 Series
Help Hotline:
1-813-978-3700 • Mon-Fri 8am-8pm • Sat-Sun 10am - 6pm
Specifications and product details subject to change without notice.
© Copyright 2014, VOLT
customersupport@voltlighting.com • 813.978.3700
Low Voltage Landscape Lighting
®
Lighting, Lutz FL USA 33549 • All rights reserved.
®
Advertisement
Table of Contents
Related Manuals for Volt 390 Series
Summary of Contents for Volt 390 Series
- Page 1 Traditions Path & Area Light 390 Series Help Hotline: 1-813-978-3700 • Mon-Fri 8am-8pm • Sat-Sun 10am - 6pm Specifications and product details subject to change without notice. © Copyright 2014, VOLT Lighting, Lutz FL USA 33549 • All rights reserved. ® customersupport@voltlighting.com • 813.978.3700...
- Page 2 INSTALLATION INSTRUCTIONS VOLT Traditions Path & Area Light ® 390 Series Important: Please Read Before Installation This luminaire is intended for installation in accordance with local codes and the National Electric Code (NEC). Failure to adhere to these codes and in- structions may result in serious injury, property damage and void the warranty.
- Page 3 Package Contents A. (1) Luminaire C. (3) Lock Ball B. (1) Tempered Glass Product Dimensions 11” 4” ” 23” Install Stake Determine desired location for mounting luminaire. Hammer stake into ground until Board flange of stake is flush to grade. To avoid dam- age to stake, place board on top of stake while hammering.
- Page 4 INSTALLATION INSTRUCTIONS VOLT Traditions Path & Area Light ® 390 Series Install Lamp Insert lamp, sold separately, with correct wattage Socket and type as marked on luminaire label. CAUTION: Do not exceed maximum wattage marked on luminaire label. NOTE: DO NOT TOUCH halogen lamp with bare hands.
- Page 5 Install Luminaire to Stake Clear away area in ground at wireway slot in top of stake. Lay luminaire pig- tail into wireway slot and screw stem into stake. If assembly does not look straight, adjust by pushing or pulling on stake Wireway Slot only.
