INSTALLATION INSTRUCTIONS
VOLT
®
VOLT
®
3602 Series
Help Hotline:
1-813-978-3700 • Mon-Fri 8am-8pm • Sat-Sun 10am - 6pm (EST)
Specifications and product details subject to change without notice.
© Copyright 2018, VOLT
customersupport@voltlighting.com • 813.978.3700
Line Voltage Landscape Lighting
Estate Size Path & Area Lights
Lighting, Lutz FL USA 33549 • All rights reserved.
®
- 1 -
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Volt 3602 Series
Summary of Contents for Volt 3602 Series
- Page 1 3602 Series Help Hotline: 1-813-978-3700 • Mon-Fri 8am-8pm • Sat-Sun 10am - 6pm (EST) Specifications and product details subject to change without notice. © Copyright 2018, VOLT Lighting, Lutz FL USA 33549 • All rights reserved. ® customersupport@voltlighting.com • 813.978.3700...
-
Page 2: Important Safety Instructions
INSTALLATION INSTRUCTIONS VOLT Estate Size Path & Area Lights ® 3602 Series Important: Please Read Before Installation To avoid the risk of fire, explosion, or electric shock, this product should be installed, inspected, and maintained by a qualified electrician only, in accordance with all applicable electrical codes. - Page 3 Package Contents A. (1) Fixture Body Product Dimensions 10.25” 10.25” 9” 38.5” 38.5” 36” 6” 6” 6” 3” 3” 3” customersupport@voltlighting.com • 813.978.3700 - 3 -...
- Page 4 INSTALLATION INSTRUCTIONS VOLT Estate Size Path & Area Lights ® 3602 Series Remove Stem Top Loosen the stem top and remove it from the top end of the stem. Stem Top Stem Install Bulb Insert the bulb with the correct...
- Page 5 Install Stem Top Thread the stem top onto the stem and hand tighten until Stem Top snug. Stem Install Stake and Conduit Ground Level Conduit Stabilizer Stake Grid Dig a hole in the ground for the conduit runs and the stake. Install the conduit.
- Page 6 INSTALLATION INSTRUCTIONS VOLT Estate Size Path & Area Lights ® 3602 Series Remove Cap from Stake Remove the cap from the stake by loosening the set screws. Set Screw Stake Install Cap to Junction Box Thread the cap onto the Junction Box.
- Page 7 Supply Wires Junction Box Screw Cover * Junction Box is not provided by VOLT® Install Junction Box to Stake Pass the main supply cable into the junction box. Place the cap back onto the stake and secure with the previously removed...
-
Page 8: Wire Connection
INSTALLATION INSTRUCTIONS VOLT Estate Size Path & Area Lights ® 3602 Series Wire Connection Wire Connectors Fixture Supply Wires Cover Ground Screw Junction Box Main Supply Cable Screw * Junction Box is not provided by VOLT® Strip the leads from the fixture supply wire and main supply cable. Using wire connectors (sold separately), connect the leads from the fixture supply wire to the main supply cable leads. - Page 9 Install Hat Finial Finial Stem Top Stem Top StemTop OPTIONAL A OPTIONAL B OPTIONAL C Place the hat onto the stem top and secure it with the finial, or thread the hat onto the stem top directly. Hand tighten until snug. Install/Replace Bulb Disconnect the power, before replacing the bulb.
- Page 10 INSTALLATION INSTRUCTIONS VOLT Estate Size Path & Area Lights ® 3602 Series w w w . v o l t l i g h t i n g . c o m - 10 -...
- Page 11 customersupport@voltlighting.com • 813.978.3700 - 11 -...
- Page 12 . v o l t l i g h t i n g . c o m Specifications and product details subject to change without notice. © Copyright 2018, VOLT Lighting, Lutz FL USA 33549 • All rights reserved.
