Data Port Specifications (Ethernet); Serial Port Specifications (Pinout Rj-45) - Extreme Networks ExtremeRouting SLX 9850-4 Hardware Installation Manual

Module
72-port 10GbE/1GbE interface module
36-port 100GbE, 60-port 40GbE, or 240-port
10GbE flex-speed interface module

Data port specifications (Ethernet)

Model Port type
SLX 9850-4 1 GbE
10 GbE
40 GbE
100 GbE
SLX 9850-8 1 GbE
10 GbE
40 GbE
100 GbE

Serial port specifications (pinout RJ-45)

Pin
1
2
3
4
5
6
7
8
ExtremeRouting SLX 9850-4 Hardware Installation Guide
9035474-02 Rev AA
Maximum power consumption
SLX 9850-8: 346 W
299 W
848 W
Number of ports Description
288 Supports up to 288 1-GbE ports with four 72-port 10GbE/1GbE interface modules
288 Supports up to 288 10-GbE ports with four 72-port 10GbE/1GbE interface
modules
960 Supports up to 960 10-GbE ports with four 36-port 100GbE, 60-port 40GbE, or
240-port 10GbE flex-speed interface modules (requires 40GbE-to-10GbE
breakout)
240 Supports up to 240 40-GbE ports with four 36-port 100GbE, 60-port 40GbE, or
240-port 10GbE flex-speed interface modules
144 Supports up to 144 100-GbE ports with four 36-port 100GbE, 60-port 40GbE, or
240-port 10GbE flex-speed interface modules
576 Supports up to 576 1-GbE ports with eight 72-port 10GbE/1GbE interface
modules
576 Supports up to 576 1-GbE ports with eight 72-port 10GbE/1GbE interface
modules
1920 Supports up to 1920 10-GbE ports with eight 36-port 100GbE, 60-port 40GbE,
or 240-port 10GbE flex-speed interface modules (requires 40GbE-to-10GbE
breakout)
480 Supports up to 480 40-GbE ports with eight 36-port 100GbE, 60-port 40GbE, or
240-port 10GbE flex-speed interface modules
288 Supports up to 288 1000-GbE ports with eight 36-port 100GbE, 60-port 40GbE,
or 240-port 10GbE flex-speed interface modules
Signal
Not supported
Not supported
RXD
GND
Not supported
TXD
Not supported
Not supported
Serial port specifications (pinout RJ-45)
Description
N/A
N/A
Receive data
Logic ground
N/A
Transmit data
N/A
N/A
