INSTALLATION
Slip the collection vessel between the isolation valves making sure that the sealing
washers are fitted and that the flow direction arrow on the body is pointing in the same
direction as the flow.
The air vent must be at the top of the collection vessel and the cover at the bottom.
Hand tighten the valves to the collection vessel before fully tightening.
W RNING: Over tightening the connection to the collection vessel can cause
irreparable damage to the vessel.
Fully tighten the compression joint on the ball valves.
The installation is now complete.
To change to the horizontal pipe configuration, loosen the retaining nut to the body
and then rotate the body to the desired orientation before re-tightening the joint.
Sealing
Washer
3
