Intersection Equipment Installation Instructions
Table 5-5. Model 1035Auxiliary Harness Connector Pin Index
Pin
Wire Color
1
Black/Brown
2
Black/Blue
3
Black/White
4
Yellow/Black
5
Yellow/Black
10
Yellow/Gray
11
Yellow/Blue
16
Black/Red
17
Black/Yellow
18
Black/Green
26
Yellow/ White
27
Yellow/Orange
31
Black/Violet
32
Black/Orange
33
White
Function
Phase 1 green input (AC+)
Phase 2 green input (AC+)
Phase 3 green input (AC+)
Future
Future
Future
Future
Phase 4 green input (AC+)
Phase 5 green input (AC+)
Phase 6 green input (AC+)
Future
Future
Phase 7 green input (AC+)
Phase 8 green input (AC+)
Green sense common (AC common)
33
