28
1. 9-pin connector (MODEM)
2. 9-pin connector (OPTICOM)
3. Terminal block TB1
4. Terminal block TB2
Intersection Equipment Installation Instructions
Figure 5-13. Auxiliary Interface Panel Installation
5. 44-pin connector J2
6. Auxiliary interface panel cable
7. Mounting plate
8. Auxiliary interface panel
