Intersection Equipment Installation Instructions
5.5.3

Auxiliary Interface Panel Installation

The Model 1030 auxiliary interface panel is a
terminal block assembly designed for easy
connections between the phase selector and the
traffic control cabinet wiring and provides a
breakout of the AIP connector on the front of the
phase selector. This assembly is required for the
following:
•
Installations using requiring more than four
outputs
•
Time Sync output operation
•
Access to the Modem and Opticom COM
ports
This panel also provides connections for green
sense and future applications. If the additional
outputs on the auxiliary interface panel is not
required, then the auxiliary harness may be used
to connect green sense. See Section 5.4.5.
NOTE: Wire gauges from 22 to 16 AWG may
be used to connect from the auxiliary
interface panel to the traffic control cabinet
wiring.
NOTE: All of the auxiliary interface panel
terminals may not be used in any given
installation.
WARNING
This procedure may expose you to AC
voltage and the risk of electric shock or
electrocution. Turn off the AC mains and
use accepted and recognized safety
precautions to avoid exposure to the risk of
electric shock or electrocution. Electric
shock may cause severe injury or death.
1. Install the auxiliary interface panel. See
Figure 5-13.
a) Determine a suitable location for the
auxiliary interface panel in the traffic
control cabinet.
b) Use the mounting plate as a template and
mark where you want to drill holes.
c) Drill the holes and fasten the panel to the
interior wall with user-supplied fasteners.
2. Connect the auxiliary interface panel cable.
See Figure 5-13.
a) Connect one end of the auxiliary interface
panel cable to the connector labeled AIP
on the front panel of the phase selector.
b) Connect the other end of the auxiliary
interface panel cable to connector J2 on
the auxiliary interface panel.
The auxiliary interface panel is now ready for
wiring connections to the traffic control cabinet.
