Operations
The monitor station sounds a melody and the indicator light of door
camera flashes after a visitor presses the "call" button of door camera
1. The indicator light(green LED) on the directory/name plate will flash after the
"call" button of door camera is pressed.
2. Pick up the handset of monitor station to talk to your visitor after a
melody.
3. If the optional electric door striker is installed it functions in the following
way.
- To unlock the door during conversation, Press door "open" button.
- The image on the screen disappears when door "open" button is
pressed.

Specifications

Enterview Multi
Remark
Power Source Regulated DC 12V
Power Consumption DC 12V, 230mA / 330mA
Display output 1Vp-p/75 , Composite CCIR/EIA, PAL/NTSC
Maximum Wiring Distance
Minimum Illuminance 0.1 Lux(B/W) / 3 Lux(Color)
Temperature -10 C ~ 40 C
Environment
Humidity Below 90%(relative)
Dimension
123W 308H 18D(mm)/4-5/6W 12-1/8H 5/7D (Inches)
Size
Weight 1Kg / 2.2 Ibs
Installation Flush Mount Type
Specification
0.65(AWG22)/0.8(AWG20)mm, 50m/165 feets
Enterview Multi
