GE AEE07KP Service Manual page 58

Description
NO.
Product Code
1 Cabinet Assy
2 Condenser Assy
3 Axial Flow Fan
4 Rear Clapboard
5 Motor Support 1
6 Fan Motor
7 Top Cover Board Sub-assy
8 Front Clapboard Sub-Assy
9 Base Plate Of Air Flue
10 Propeller Housing
11 Air Outlet Sub-Assy
12 Air Door Lever
13 Swing Lever
14 Swing Lever2
15 Step Motor
16 Swing Blade Support
17 Crank
18 Air Louver
19 Centrifugal Fan Sub-Assy
20 Front Clapboard of Propeller Housing
21 Evaporator Assy
22 Compressor and Fittings
23 Compressor Overload Protector(External)
24 Compressor Gasket
25 Capillary Sub-assy
26 Inhalation Tube Sub-assy
27 Discharge Tube
28 Water Tray
29 Chassis Sub-assy
30 Drainage hole Cap
31 Drainage Box
32 Cabinet Fastener
33 Chassis Clamp
34 Power Cord
35 Electric Box Assy
36 Capacitor CBB61
37 Capacitor CBB65
38 Electric Box
39 Transformer
40 Main Board
41 Ambient Temperature Sensor
42 Temperature Sensor
56
Part Code
AED12KP
CC052024400_K93412
01431108
01101117
10331163
01231502
01701605
150116066
01251503
01231607
01221602
12101602
2000103601
10581601
10581602
10581021
1521211601
10581603
73011001
10511601
10311501
01231604
01001217
00121003
00180095
76710278
03001508
03631565
03641001
12411007
01201109P
76711012
20181801
26251601
01211601
4002048914
20101448
33010009
33000018
20111018
43110236
30132049
390000451
390000596
Service Manual
Qty
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
1
1
1
1
1
3
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
Installation and Maintenance
