Description
NO.
Product Code
1 Cabinet Assy
2 Condenser Assy
3 Axial Flow Fan
4 Rear Isolation Sheet With Spot Welding
5 Motor Support
6 Fan Motor
7 Top Connecting Plate Assy
8 Front Clapboard Sub-Assy
9 Base Plate Of Air Flue
10 Step Motor
11 Propeller housing Assy
12 Propeller Housing
13 Base of Swing Louver
14 Air Inlet Door
15 Cross Beam Sub-Assy
16 Air Louver
17 Centrifugal Fan Sub-Assy
18 Front Clapboard of Propeller Housing
19 Evaporator Assy
20 Compressor and Fittings
21 Compressor Overload Proctector(External)
22 Compressor Gasket
23 Capillary Sub-assy
24 Inhalation Tube Sub-assy
25 Discharge Tube
26 Water Tray
27 Chassis Sub-assy
28 Drainage hole Cap
29 Drainage Box
30 Chassis Clamp
31 Power Cord
32 Electric Box Assy
33 Transformer
34 Electric Box
35 Terminal Board
36 Sleeving
37 Main Board
38 Temperature Sensor
39 Ambient Temperature Sensor
40 Capacitor CBB61
41 Display Board
42 Control Panel A
38
Part Code
AEE07KP
CC052005800_K93320
01431010
0110134501
10331160
01231097
01701123
15011060
01381018
01231388
01221154
15211008
26151350
12101121
10521123
26111124
24241200
10511123
10311125
01231203
01001805
00101261
00183101/00181044
76710232
03001971
03631865
03611624
12411003
0120122501P
76711012
20181125
01211151
4002048914
20101451
43110236
20101126
42010157
4203240201
30132096
390000596
390000451
33010010
30562053
20161220
