Event Lighting M1S80W User Manual page 7

User Mode ①
Users
Edit User ③
-Password-
Calibration ③ Pan
:
Name
Rdm Mode
Fixture ID ③
-Password-
PID Code
DMX On Cable
Wireless Set ①
Reset Connect
Basic Reload( ① )
Program Reload( ② )
Reload Default ---Password---
Private Reload( ③ )
All Reload
DMX Receive
Slave Receive
Play ①
Sequence
Music
Chase Part 1
Select Chase ② Chase Part 2
Chase Part 3
Chase 1
Edit Chase ② :
Chase 8
Edit Scene 001
~ Edit Scene 250
Edit Scenes ②
Scenes Record ScXX=>ScXX
6
Standard
Extended
:
User
Max Channel = XX
PAN = CH01
:
=xxx
=xxx
:
ON/OFF
ON/OFF
ON/OFF
ON/OFF
XXX
ON/OFF
ON/OFF
Slave Receive 1,2,3
Master / Alone
Master / Alone
Chase 1 ~ 8 Chase 1
Chase 1 ~ 8 Chase 2
Chase 1 ~ 8 Chase 3
Chase Test
Step 01
Step 64
Pan, Tilt ,......
--Fade Time--
--Secne Time--
DMX Input
www.event-lighting.com.au
Standard mode
Extended mode
:
User program mode
Edit users mode
Password: 050
Calibrate channel value
Name
RDM Mode
Password: 050
Set PID of RDM
DMX On Cable
Reset Connect
Basic Reload
Program Reload
Password: 050
Private Reload
All Reload
DMX Receive
Choose slave position
Run Sequence
Music mode
Select and run auto program
Test
=xxx Beginning scene
=xxx Ending scene
=xxx Input manual scene
=xxx Modify manually fading time
=xxx Modify manually scene time
Input scene from exterior controller
Auto Input scenes
