Technical Data - Siemens SIMOVERT SLP Operating Instructions Manual

SIMOLINK Pulse Generator
3

Technical Data

Product name
Order number
Size [mm]:
– Width
– Height
– Depth
Weight
Degree of protection
Degree of pollution
Mechanical strength:
– In steady-state operation
– During transportation
Climate class
Cooling method (operation)
Permissible ambient or
coolant temperature:
– In operation
– In storage
– During transportation
Permissible humidity rating:
– Transport/storage
– In operation
Power supply
Rated supply voltage
Power consumption
Encoder interface
Tracks A and B
Supply voltage:
– Electrical isolation
Fiber-optic cable connection
Transmitter power
Fiber-optic cable modules
– Transmitter
– Receiver
Siemens AG GWE-477 764 4070.76 J
SIMOVERT MASTERDRIVES
02.2001
SLP
6SX7005-0AD00
Device dimensions (housing)
35 (35)
118 (107)
88 (80)
Approx. 280 g
IP20 to EN 60529
Not applicable
Moisture condensation is not permissible in operation
Not applicable
Class 3K3 to DIN IEC 721-3-3 (in operation)
Convection
0 °C to
–25 °C to
–25 °C to
Relative air humidity
≤ 95 %
≤ 85 % (condensation not permitted)
DC +24 V (+20.4 V to +28.8 V)
Approx. 140 mA
RS422 to EIA422 standard
Internal
Isolating voltage 500 V DC to 24 V voltage supply
Fixed (maximum transmitter power defined for SIMOLINK)
Hewlett Packard
HFBR 1528
HFBR 2528
Table 3-1 Technical data
Operating Instructions
+55 °C
+70 °C
+70 °C
Technical Data
3-1
