Installation
Figures
1
2
3
2
1
18
Holding the wire drum [1] with one hand, unwind the
6.
measuring wire [3] approximately 500 mm (19.69 in).
Secure the wire [3] temporarily with the tape [2].
7.
Insert the wire ring [4] into the drum housing.
8.
Pull the wire ring out through the calibration window.
9.
3

• Take special care to not hit the wire drum against the
4
housing due to strong magnet force.
• Handle the measuring wire with care.
A0028879
Insert the wire drum [3] temporarily into the drum housing.
10.
Hook the displacer [2] on the wire ring.
11.
Secure the displacer to the measuring wire using the
12.
securing wire [1].

Handle the measuring wire with care. It may kink.
1
A0027984
Remove the wire drum from the drum housing and unwind
13.
the measuring wire down approximately
500 mm (19.69 in).
Hold the wire drum [1] up and place the displacer [2] into
14.
the calibration window.
Hold the displacer at the center of the calibration window.
15.
Hold the other hand (wire drum) up to add tension to the
16.
measuring wire in order not to drop the displacer rapidly.
2
A0027986
