Proservo NMS83
7.8.3 Modbus or V1 output
1
E
2
1
CDI
i
1 3
F
2 4
HR
WP
POWER
SIM
 30 Possible locations of the Modbus or V1 modules (examples); depending on the device version these
modules may also be in slot B or C .
Depending on the order code the device may have one or two Modbus or V1 communication
interfaces. These are configured in the following submenus:
Modbus
• Setup → Advanced setup → Communication → Communication Interface 1 to 2
→ Configuration
• Setup → Advanced setup → Communication → Communication Interface 1 to 2 → Integer
conversion
V1
• Setup → Advanced setup → Communication → Communication Interface 1 to 2
→ Configuration
• Setup → Advanced setup → Communication → Communication Interface 1 to 2 → V1 input
selector
Endress+Hauser
D
1 2 3 4
C
1 2 3 4
B
1 2 3 4
on
A
1 2 3 4
5 6 7 8
5 6 7 8
D
1 2 3 4
D1-4
A
1 2 3 4
A1-4
Commissioning
A0031200
