Let go of the displacer [2].
17.
Remove the tape from the wire drum [5].
18.
Insert the wire drum into the drum housing.
19.
Mount the bracket [4].
20.

Be sure that the wire is wrapped correctly in grooves.
Turn on the power of NMS8x and move the displacer up
21.
using the Move displacer wizard→  41 until the wire
ring can be seen in the calibration window.

• Confirm that there are no kinks or other defects in the
• Confirm that the displacer does not touch the inner wall of
1
Perform sensor calibration.
22.

For sensor calibration, →  43
2
Perform reference calibration.
23.
A0032444

For reference calibration, →  45.
Mount the drum housing cover [5] and the calibration
24.
window cover [1].
Perform drum calibration.
25.

For drum calibration, →  46
Procedures
measuring wire.
the nozzle.
Installation
