CIS VCC-4K2 Product Specification & Operational Manual

3g-sdi × 4ch 4k uhdtv cmos color camera
Hide thumbs Also See for VCC-4K2:
Table of Contents

Advertisement

Quick Links

Download this manual
VCC-4K2
Rev. 905-0087-02
3G-SDI × 4ch
4K UHDTV CMOS Color Camera
VCC-4K2
Product Specification
& Operational Manual
CIS Corporation
©2017 CIS Corporation. All rights reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VCC-4K2 and is the answer not in the manual?

Questions and answers

Related Manuals for CIS VCC-4K2

Summary of Contents for CIS VCC-4K2

  • Page 1 VCC-4K2 Rev. 905-0087-02 3G-SDI × 4ch 4K UHDTV CMOS Color Camera VCC-4K2 Product Specification & Operational Manual CIS Corporation ©2017 CIS Corporation. All rights reserved.

  • Page 2: Table Of Contents

    Quick Reference Table for Gain Settings ....................19 Quick Reference Table for Shutter Settings .................... 20 Factory Settings ..........................21 Dimensions ..............................22 Case for Indemnity ............................23 Product Warranty ..........................23 CMOS Defective Pixels ........................23 Product Support ............................23 ©2017 CIS Corporation. All rights reserved.

  • Page 3: Handling Precautions

    □ The camera must not be used under conditions or environments other than specified in this manual. 1.3 Disclaimers (Exception Clause) CIS Corporation shall be exempted from taking responsibility and held harmless for damages or losses incurred by the following cases.

  • Page 4: Product Outline

    VCC-4K2 Rev. 905-0087-02 Product Outline VCC-4K2 is a small 4K color camera module utilizing a 1.0" type global shutter CMOS image sensor. 4K UHDTV 60p/59.94p/50p/30p/29.97p/25p/24p/23.98p (3G-SDI ×4ch), 1080 60p/59.94p/50p (3G-SDI ×1ch), and 1080 60i/59.94i/50i (HD-SDI ×1ch) are corresponded. 2.1 Features □...

  • Page 5: Specifications

    Off, 100%, 95%, 90%, 85%, 80%, 75% Color space BT.709, BT.2020 Master Pedestal -100 ~ 0 ~ +100 Pedestal (R,G,B) RGB -100 ~ 0 ~ +100 Color balance RGB 0 ~ 100 ~ 200 ©2017 CIS Corporation. All rights reserved.
  • Page 6 (100G) for ±X,±Y, and ±Z, 6 directions. (Without packaging) Operation Guaranteed Temperature -5 ~ +45℃ Humidity 20 ~ 80%RH with no condensation. Storage Temperature -25 ~ +60℃ Humidity 20 ~ 80%RH with no condensation. ©2017 CIS Corporation. All rights reserved.

  • Page 7: External Connector

    Model Name : BCJ-BPLHA (CANARE) Pin No. Description 3G-SDI output CH0 (Upper left) 3G-SDI output CH1 (Upper right) 3G-SDI output CH2 (Lower left) 3G-SDI output CH3 (Lower right ) Shell Connected to chassis GND ©2017 CIS Corporation. All rights reserved.

  • Page 8: Functions

    In addition to the corrected defective pixels data registered at ex-factory, users can detect, register, or delete defective pixels data occurred after shipping out from our factory. Please refer to the Section 5.2, Command List for the details. ©2017 CIS Corporation. All rights reserved.

  • Page 9: Defective Pixels Type

    For example, if the defective pixel is at (943,0) position, the data shall be registered only to the reed Area 0. However, if the defective pixel is at (944,0) position, the data shall be registered to both of the reed Area 0 and 1. ©2017 CIS Corporation. All rights reserved.

  • Page 10: Notes For Defective Pixels Correction

    Even if the user specify a defective point with coordinate to register or delete, it cannot be executed if the data was one of the ex-factory data. Neglecting this instruction may cause not only inappropriate pixel defect correction but also failure of getting proper images. ©2017 CIS Corporation. All rights reserved.

  • Page 11: Serial Communication

    [Prompt (> and space)] 【Example of SU Command】 To set 30 to the Command No.10 [Send] SU[sp]10[sp]30[¥r] [Returned value] SU[sp]10[sp]30[¥r][¥n] [Echo back] [Returned value] [¥r] [¥n] [Line feed] [Returned value] >[sp] [Prompt + (> and space)] ©2017 CIS Corporation. All rights reserved.

  • Page 12: Command List

    18: UHDTV 2-Sample Interleave 30p 444 (Level A) 19: UHDTV 2-Sample Interleave 29.97p 444 (Level A) 20: UHDTV 2-Sample Interleave 25p 444 (Level A) 21: UHDTV 2-Sample Interleave 24p 444 (Level A) 22: UHDTV 2-Sample Interleave 23.98p 444 (Level A) ©2017 CIS Corporation. All rights reserved.
  • Page 13 ※Please refer to the Setting range: (77) Section 5.4 Quick 1/13600 ~ 1/23.98s 1/13600s Reference Table for Shutter Settings. (0x4D~0xAAD6） 0： Average 1： Center-Weighted Metering Mode This is to set metering mode. 2： Spot 3： Backlight Compensation ©2017 CIS Corporation. All rights reserved.
  • Page 14 1 : raise 1step(1/4EV) shutter mode is at Manual. (Dedicated to SU) Current Gain None None This is to acquire current gain.(Dedicated to GU) To aquire current shutter value (Dedicated to Current Shutter None None ©2017 CIS Corporation. All rights reserved.
  • Page 15 This is to set the shift amount of WB gain to CC WB CC Shift -10~10 direction. This is to acquire current Red Gain. (Dedicated to Current Red Gain None None This is to acquire current Blue Gain. (Dedicated to Current Blue Gain None None ©2017 CIS Corporation. All rights reserved.
  • Page 16 This is to set color saturation level. 0 : Off Noise Reduction This is to set noise reduction. 1 : On 0: Auto Color Correction 1: Standard This is to set color correction. 2: Fluorescent Light ©2017 CIS Corporation. All rights reserved.
  • Page 17 This is to set the font color of the 3: Magenta selected text of OSD. Highlight Color 4: Green If the same color as the text color is 5: Cyan selected, it shall be an error. 6: Yellow 7: White ©2017 CIS Corporation. All rights reserved.
  • Page 18 1 (Fixed) None data, where to store, defective pixel correction data shall be saved. (Dedicated to SU) Microcomputer This is to acquire version information. Version Information version None (Dedicated to GU) 2: FPGA version ©2017 CIS Corporation. All rights reserved.
  • Page 19 Only user registered data can be changed, but the data at Ex-Factory would never be able to be changed.  The pixels which have already been registered as ex-factory data cannot be registered by user.  ©2017 CIS Corporation. All rights reserved.

  • Page 20: Quick Reference Table For Gain Settings

    6658043 006597FB 114.035 41.141 7473400 007208F8 128.000 42.144 8388608 00800000 143.675 43.148 9415894 008FACD6 161.270 44.151 10568984 00A14518 181.019 45.154 11863283 00B504F3 203.187 46.158 13316085 00CB2FF5 228.070 47.161 14946800 00E411F0 251.189 48.000 16461899 00FB304B ©2017 CIS Corporation. All rights reserved.

  • Page 21: Quick Reference Table For Shutter Settings

    000016C1 1/250 4194 00001062 1/350 2995 00000BB3 1/500 2097 00000831 1/725 1446 000005A6 1/1000 1048 00000418 1/1500 000002BB 1/2000 0000020C 1/3000 0000015D 1/4000 00000106 1/6000 000000AE 1/8000 00000083 1/9600 0000006D 1/11200 0000005E 1/13600 0000004D ©2017 CIS Corporation. All rights reserved.

  • Page 22: Factory Settings

    Normal Color Saturation Noise Reduction Color Correction Auto Color Suppression Color Space BT.709 Text Color White Highlight Color Cyan Camera Setting Store/Load LTC Mode GenLock V Offset GenLock H Offset H Flip V Flip ©2017 CIS Corporation. All rights reserved.

  • Page 23: Dimensions

    VCC-4K2 Rev. 905-0087-02 Dimensions ©2017 CIS Corporation. All rights reserved.

  • Page 24: Case For Indemnity

    Products out of warranty period will be subject to charge. CIS repairs the products as long as it is repairable. CIS shall be exempted from taking responsibility and held harmless for damages or losses incurred by the following cases. In case damages or losses are caused by earthquake, lightning strike, fire, flood or other acts of God.
