- Page 1 Flow XT Installation Instructions...
-
Page 2: Before Beginning Installation
Before Beginning Installation • Read through the entire instruction thoroughly • A minimum of 2 persons is required for this assembly • These instructions reflect typical assemblies. They may not match your specific configuration. • Tables 120” and less are shipped with beams and power island attached to the bases. -
Page 3: Required Tools
Required Tools • Drill Driver • #2 and #3 Phillips Bit • 5/32” Drill Bit • ¼” Allen Wrench • 1/8” Allen Wrench • Level • Draw-Tight Fastener Tool (included) -
Page 4: Included Hardware
Included Hardware • Bolt – 3/8” UNC x 5/8” L-HW2248 • Screw – 10-12 x 1-1/4” PHIL • Screw - #12 x 1” PAN-PHIL • Draw-Tight Hardware • Bolt – 5/16 – 18 x 5/8 Fit Socket Head Cap (post base leg only) - Page 5 Flow XT Table...
- Page 6 Flow XT Table Exploded End Base Center Base Main Beam Power Island Power Island Mounting Bracket Beam Shroud...
- Page 7 Installation Prep – 3-Piece or 4-Piece Tops • 3-Piece and 4-piece tops include gussets for extra support. – Locations are marked on the main beam. • Slide the gusset’s clamp bar onto the main beam BEFORE attaching the beam to the bases (facing outward).
- Page 8 Step 1: Tables over 120” • Locate the beam labels and match for correct placement of the bases. • Loosen clamp bars from base. • Attach end bases by sliding the clamp bars into the beams. – Beams should be 1/8” from the top of the base panel. •...
- Page 9 Step 2: Power Island • Level the frame by adjusting the base glides. – BEFORE adding the power island. • Place power island onto frame. Use the 3/8” x 5/8” UNC bolts to hold the power island brackets to the beams. –...
- Page 10 Step 3: Storage Well Installation (if applicable) • Place the storage well in the power island. • Attach the well to the power island using the bracket and ¼ - 20 x ¾ PHIL flat fastener. • Tighten the fastener to ensure no gaps.
-
Page 11: Step 4: Top Installation
Step 4: Top Installation • Open the doors on the power island to avoid damage to the top. • Slide the top within 4 inches of the two halves connecting. STOP. Close the doors on the power island before continuing to join the two halves. - Page 12 Step 5: Work Surface Alignment • Align the “L” shaped notes on the bottom of the top with the corners of the bases. • Center the power island with the top before fastening to the bases. • With multi-piece tops, join the pieces with the provided draw tight hardware. •...
- Page 13 Step 6: Fastening • Fasten these to the underside of the top with 1” #12 screws. – Storage Well – Power Island Brackets – Gussets from the frame • Tighten the cap screws that attach the power island to the beams •...
- Page 14 Power Island Trouble Shooting • Power Island flush to table surface: • When the power island is not flush to the underside of the table, loosen the cap screws that connect the mounting bracket to the power island. • Push the power island up against the underside of the table and retighten the bolts. •...
- Page 15 Power Island Trouble Shooting cont. Power Island Door Alignment: • When the power island doors are not aligning or laying flush to one another, use a rubber mallet to lightly tap into place. – Open the door slightly, and tap until the door aligns. Repeat for each affected door. •...
- Page 16 Flow XT Table – Post Leg Base...
- Page 17 Flow XT Table – Post Leg Base Exploded End Base Center Base Main Beam Power Island Power Island Mounting Shroud Beam Shroud...
- Page 18 Installation of Post Leg Base • Slide the clamp bars from the end base into a beam. • Tighten the screws that fasten the end baes to the beam. • Then continue with Step #2 in instructions above.
