801 Avenida Acaso, Camarillo, Ca. 93041 • (805) 494-0622 • Fax: (805) 494-8861
www.sdcsecurity.com • E-mail: service@sdcsecurity.com
1
Remove the existing
components shown.
P:\INSTALLATION INST\ELECTRIFIED LOCKSETS\INST-SK-82.vsd
INSTALLATION INSTRUCTIONS
SK-82 FIELD ELECTRIFICATION KIT
SARGENT 8204 MORTISE LOCKSET
2
Install new Latch Retraction Arm supplied
with Electrification Kit as shown
REV C
11-18
Page 1
Any suggestions or comments to this instruction or
product are welcome. Please contact us through
our website or email engineer@sdcsecurity.com
