A. Door Preparation:
1. Measure desired height from finished floor, mark a horizontal line on door and door edge.
2. Align template on edge of door with applicable horizontal at height line. Check the chart for drilling trim
holes on template and mark only holes for lock function being installed.
Height
line
3. Mortise door edge according to measurements on
installation template and drill proper holes for trim.
4. Recess for face plate, the dimension is:
L 8-1/32" x W 1-5/16" x D 7/32".
7/32"
P:\INST INSTRUCTIONS\ELECTRIFIED LOCKSETS\INST-Z7835-C
INSTALLATION INSTRUCTIONS
24VDC MORTISE LOCK
C L
of lever
or knob
REF G
Z7835
of door edge
C L
OPTIONAL
DOOR CORE DRILLING GUIDE
#7000-DG
02-21
Page 1
Installation
template
of cylinder
C L
of lockcase
C L
of lever or knob
C L
Vertical centerline
Any suggestions or comments to this instruction or
product are welcome. Please contact us through
our website or email engineer@sdcsecurity.com
