CONCEALED VERTICAL ROD DEVICES
INSTALLATION INSTRUCTIONS
These instructions are presented in a step by step sequence.
Please read it through before installation.
P:\INSTALLATION INST\Mechanical Hardware\INST-S6800.vsd
801 Avenida Acaso, Camarillo, Ca. 93012
• (805) 494-0622 • www.sdcsecurity.com
E-mail: service@sdcsecurity.com
S6800 SERIES
PANIC/FIRE EXIT
Rev A
01/13
Page 1
