Scroll to the PRINTER SETUP command
and press F1.
You may print either the current display or
a report. Use F2 or F3 to select the
desired printing job.

LCD TEST

Scroll to LCD TEST and press F1. The
meter will execute several patterns to test
each of the LCD's display points. The
patterns should appear as all white, all
black, vertical stripe and then checker-
board.
NOTE: If the temperature is below
0°C, the display speed of the LCD will
slow down.
Once the parameters have been set to
your specifications, scroll to PRIOR MENU
and press F1. This returns you to the SET
UP display.
Measurement Display
Once your meter's parameters have been
established and you are back to the main
set up menu, use F2 or F3 to scroll to the
MEASUREMENT command box.
! TRILITHIC
19:16:30
GENERAL GENERAL GENERAL
GENERAL GENERAL
# PRINTER SETUP
PRINT SCREEN
PRINT REPORT
ENTER
Model One Operating Manual
Model One Setup
SETUP
– 23
