Infinite Peripherals Apto Infinea X Mini Quick Start Manual

Apto
™
Infinea X Mini
®
Charging Cup
QUICK START GUIDE
GETTING STARTED
INSTALLATION (See Installation Diagram)
1. Ensure that the environmental conditions are
within appropriate operating specifications for
the charger, as well as for the Infinea X Mini and
iOS device.
2. Clip the charging cup onto the bottom of Infinea
X Mini device and check that cup is properly
aligned and fully seated on the bottom of the IX
Mini device.
3. Plug USB connector end of Infinea X Mini
Charging Cup into approriate power supply (5.2V
2.4A, not inlcuded).
4. Confirm that the Infinea X Mini LED indicator
turns green to indicate charging is active.
REMOVAL (See Removal Diagram)
1. Grip the bottom of the cup with palm of hand.
2. Pull down on the rear tab with fingertips to
unlock cup from device.
3. Seperate the charging cup from the device.
Note: When the Infinea X Mini is seated correctly, the LED will turn green to indicate the charging status. The time to charge a completely discharged Infinea X
Mini Standard Battery is approximately 3.5 hours.
ABOUT YOUR APTO™ INFINEA® X MINI
Installation
Removal
PRODUCT SPECIFICATIONS
The following table describes Infinea X Mini Charging Cup specifications.
Mechanical
Compatibility:
Weight:
Dimensions:
Cable Length:
Electrical
Connector:
Input:
Environmental
Operating Temperature:
Storage Temperature:
INFINEA X MINI CHARGING CUP
Infinea X Mini with iPad mini 3
Infinea X Mini with iPad mini 2
63 g (2.22 oz.)
81.6 mm x 50.1 mm x 32.7 mm (3.21" x 1.97" x 1.29")
3'
USB A
5.2V 2.4A DC
+32°F to +95° F (0°C to +35°C)
-4°F to +113° F (-20°C to +45°C)
CHARGING CUP
