QUICK START GUIDE
Linea Pro® 7i
Pistol Grip
Charging Station
(1-Unit)
For Linea Pro 7i Pistol Grips
Assemble Your Charging Station
The Linea Pro Pistol Grip Charging Station is designed specifically to
charge the Linea Pro 7i and your iOS device. The iOS device must be
properly installed in the Linea Pro 7i for charging to occur.
1. Place the charging station on a sturdy, clean, and dry surface in an open,
well-ventilated area away from direct sunlight.
2. Plug in the DC barrel plug, included with the charging station, to the DC
port on the front of the charger.
3. Connect the AC power adapter to a power outlet.
4. Insert the pistol grip into the charging station.
5. When the pistol grip is seated correctly, the LED on the front of the
charger is green to indicate power is supplied to the iOS device.

Charging Status

The Linea Pro 7i Pistol Grip Charging Station (1-Unit) displays two LEDs
to indicate the charge status.
LED Status Indictors
Green Power is supplied to the charging station.
No LED No device is in the charging station or the power supply
is not attached to the charging station.
:
Note
For device charging status, refer to the user documentation for the Linea Pro
7i Pistol Grip and Linea Pro 7i unit.
Troubleshooting
The LED does not illuminate when the Linea Pro 7i Pistol Grip is inserted
into the charging station, or the Linea Pro iOS device is not charging.
• Ensure the DC barrel plug is securely inserted into the DC port on the
front of the charging station and the AC power adapter is plugged into a
working power outlet.
• Ensure the unit is seated properly in the charging station.
It takes an excessive amount of time to fully charge the battery.
• Verify ambient temperature meets the operating temperature
requirements.
* Operating: 0°C to +30°C (+32°F to +86°F)
