QUICK START GUIDE
Infinea® Tab Lite
For iPhone® 6 Plus/6s Plus /7Plus/8 Plus
Attach Your iPhone
to the Otterbox uniVERSE Case
1. Insert your iOS device into the Otterbox uniVERSE case gently.
2. With the iOS device face up, slide it onto the Lightning™ connector
until you hear a click.
Charge Your Infinea Tab Lite
Before first use, the battery must be fully charged for at least 1 hour and
30 minutes.
• Connect the USB charger cable into the USB port, which is on the side of
the unit.
Battery Status LEDs
• To view the LEDs, press the battery status button on the back of the
unit.
• If the unit is fully discharged, it may only be reactivated at Infinite
Peripherals.
Status Description
White Unit is turned off
Flashing green Battery is charging
Solid green Battery is fully charged
Magnetic Card Reader
1. Face the magnetic card reader downward.
2. With a single motion, swipe a card through the reader until it is read
successfully.
3. Keep the edge of the card on the inner base of the reader so the stripe passes
over the read head evenly.
Contactless Card Reader
1. Place a card over the logo on the back of the unit.
2. Keep the card in place until you see the transaction is complete. Data is read,
and then sent from the Infinea Tab Lite to your iOS device.
:
Note
Keep the face of the card/tag flat with the receiver/transmitter and as
close as possible to the reader.
