Connect The Scsi Signal Cable; Terminate The Scsi Bus - Tandberg Data Tape Backup System DLT4000 Installation Manual

Tandberg Data
If the Tandberg DLT4000 is
The last or only device on the bus
and you are going to terminate the
cables externally
Not the last or only device on the
SCSI bus
2-8
Installing and Configuring the Tandberg DLT4000 Drive

2.5.2. Connect the SCSI Signal Cable

2.5.3. Terminate the SCSI Bus

Then
1. Connect the SCSI terminator to one of
2. Snap the wire cable clamps into place or
Be sure to install the terminator at the end
of the bus.
the SCSI signal connectors on the
Tandberg DLT4000 rear panel.
tighten screws (whichever is supplied) to
secure the terminator.
Tandberg DLT4000 Installation Guide
