Removing the Rear Top Cover

Before undertaking any upgrade procedure it is necessary to remove the rear top
cover to access the components.
1. Turn off the computer and disconnect all cables and peripherals.
2. Carefully place the computer flat with the LCD facing down (make sure you cover
the LCD to avoid scratches) so that you may access the rear cover.
3. Remove screws -
1
1
.
4
2
3 4
Removing the Rear Top Cover 6 - 3
Upgrading The Computer
Figure 6 - 1
Rear Top Cover
Screws
6
