Disassembly

Disassembly Steps

The following table lists the disassembly steps, and on which page to find the related information. PLEASE PERFORM
THE DISASSEMBLY STEPS IN THE ORDER INDICATED.
To remove the Battery:
1. Remove the battery
To remove the HDD:
1. Remove the battery
2. Remove the HDD
To remove the System Memory:
1. Remove the battery
2. Remove the HDD
3. Remove the system memory
To remove the Wireless LAN Module:
1. Remove the battery
2. Remove the HDD
3. Remove the wireless LAN
To remove the Bluetooth Module:
1. Remove the battery
2. Remove the HDD
3. Remove the Bluetooth
2 - 4 Disassembly Steps
page 2 - 5
page 2 - 5
page 2 - 6
page 2 - 5
page 2 - 6
page 2 - 8
page 2 - 5
page 2 - 6
page 2 - 9
page 2 - 5
page 2 - 6
page 2 - 10
