Chapter 3: System Setup
Installing a SO-DIMM Memory Module
Remove the bottom cover before installing a SO-DIMM.
1. Locate the SO-DIMM socket.
SO-DIMM Socket
Copyright © 2019 NEXCOM International Co., Ltd. All Rights Reserved.
2. Insert the module into the socket at an approximately 30 degrees angle.
The ejector tabs at the ends of the socket will automatically snap into the
locked position to hold the module in place.
24
Memory Module
NISE 4200 User Manual
