Chapter 4: BIOS Setup
Power & Performance
This section is used to configure the power management features of the CPU.
Aptio Setup Utility - Copyright (C) 2019 American Megatrends, Inc.
Advanced
CPU - Power Management Control
Intel(R) SpeedStep(tm) [Disabled]
C states [Disabled]
Version 2.20.1271. Copyright (C) 2019 American Megatrends, Inc.
Intel SpeedStep
® TM
Enables or disables Intel SpeedStep technology.
C states
Enables or disables CPU C states support for power saving.
Copyright © 2019 NEXCOM International Co., Ltd. All Rights Reserved.
Trusted Computing
This section is used to configure Trusted Platform Module (TPM) settings.
Allows more than two frequency
ranges to be supported.
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Security Device Support
Enables or disables BIOS support for security device. O.S will not show
Security Device. TCG EFI protocol and INT1A interface will not be available.
SHA-1 PCR Bank
Enables or disables SHA-1 PCR Bank.
SHA256 PCR Bank
Enables or disables SHA256 PCR Bank.
44
Aptio Setup Utility - Copyright (C) 2019 American Megatrends, Inc.
Advanced
TPM20 Device Found
Firmware Version: 0.0
Vendor:
Security Device Support [Enable]
Active PCR banks SHA-1
Available PCR banks SHA-1
[Disabled]
SHA-1 PCR Bank
SHA256 PCR Bank [Disabled]
Pending operation [None]
[Enabled]
Platform Hierarchy
Storage Hierarchy [Enabled]
Endorsement Hierarchy [Enabled]
TPM2.0 UEFI Spec Version [TCG_2]
Physical Presence Spec Version [1.3]
TPM 20 InterfaceType [CRB]
Device Select [Auto]
Version 2.20.1271. Copyright (C) 2019 American Megatrends, Inc.
Enables or Disables BIOS
support for security device. O.S.
will not show Security Device.
TCG EFI protocol and INT1A
interface will not be available.
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
