Nexcom NISE 4200 User Manual page 59

Chapter 4: BIOS Setup
Pending operation
Schedules an operation for the security device.
Platform Hierarchy
Enables or disables platform hierarchy.
Storage Hierarchy
Enables or disables storage hierarchy.
Endorsement Hierarchy
Enables or disables endorsement hierarchy.
TPM2.0 UEFI Spec Version
Configures the TPM 2.0 UEFI spec version.
Physical Presence Spec Version
Configures the physical presence spec version.
Device Select
Configures the TPM version. TPM 1.2 will restrict support to TPM 1.2 devices
and TPM 2.0 will restrict support to TPM 2.0 devices. Auto will support
both TPM 1.2 and 2.0 devices with the default set to TPM 2.0 devices if not
found, and TPM 1.2 devices will be enumerated.
Copyright © 2019 NEXCOM International Co., Ltd. All Rights Reserved.
NCT6106D Super IO Configuration
This section is used to configure the serial ports.
Aptio Setup Utility - Copyright (C) 2019 American Megatrends, Inc.
Advanced
NCT6106D Super IO Configuration
Super IO Chip
Serial Port 1 Configuration

Serial Port 2 Configuration

Serial Port 3 Configuration

Serial Port 4 Configuration

Serial Port 5 Configuration

Serial Port 6 Configuration

Version 2.20.1271. Copyright (C) 2019 American Megatrends, Inc.
Super IO Chip
Displays the Super I/O chip used on the board.
45
Set Parameters of Serial Port
1 (COMA)
NCT6106D
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
