DIMENSION SKETCH

QUARTZ
QUARTZ
F
E
A
D
B
C
Model
A
B
C
D (Min~ Max)
E
F
QUARTZ
399 mm
260 mm
410.5 mm
63 mm ~ 115 mm
510.15 mm
590 mm
8
R
