Enclosure Dimensions (H X W X D) - Altronix Trove T2KHK3F12 Installation Manual

1.25"
(31.75mm)
6.25"
(21.59mm)
(158.75mm)
1.25"
(38.1mm)
(31.75mm)
G
(25.4mm)
Altronix is not responsible for any typographical errors.
140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056
web site: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty | Made in U.S.A.
IIT2KHK3F12
- 4 -

Enclosure Dimensions (H x W x D):

27.25" x 21.75" x 6.5" (692.2mm x 552.5mm x 165.1mm)
2.00" 5.25"
(50.8mm) (133.35mm)
0.85"
1.5"
27.00"
(685.8mm)
0.85"
(21.59mm)
1.00"
2.00" 5.25"
(50.8mm) (133.35mm)
21.50"
(546.1mm)
3.50" 3.50"
(88.9mm) (88.9mm)
0.5625"
(14.29mm) 1.77"
(44.96mm)
2.415"
(61.34mm)
19.80"
(502.92mm)
7.00"
(177.79mm)
K04S
5.25"
(133.35mm)
0.685"
(17.399mm)
Knockouts
6.25"
1.125" (28.32mm)
(158.75mm)
0.885" (22.479mm)
1.25"
(31.75mm)
5.25" 2.00"
(133.35mm) (50.8mm)
2.00"
(50.8mm)
6.75"
(171.45mm)
8.25"
(209.54mm)
8.00"
(203.2mm)
2.00"
(50.8mm)
1.25"
(31.75mm)
MEMBER
T2KHK3F12
