Altronix TROVE T2KHK7F12 Installation Manual

Access & Power Integration
Altronix/Kantech Kits
Models Include:
T2KHK3F12
12 Door Kit with Fused Outputs
Fully assembled kit includes:
- Trove2 enclosure with TKH2 Altronix/Kantech backplane
- One (1) eFlow6NB - Power Supply/Charger
- One (1) T1618300K - Transformer
- One (1) ACM4 - Fused Access Power Controller
- One (1) ACM8 - Fused Access Power Controller
T2KHK7F12
12 Door Kit with Fused Outputs
Fully assembled kit includes:
- Trove2 enclosure with TKH2 Altronix/Kantech backplane
- One (1) eFlow104NB - Power Supply/Charger
- One (1) ACM4 - Fused Access Power Controller
- One (1) ACM8 - Fused Access Power Controller
All components of these Trove kits are UL Listed sub-assemblies.
Please refer to the included corresponding Sub-Assembly Installation Guides for further information.
Installation Guide
All registered trademarks are property of their respective owners.
Rev. 042924
Installing Company: _________________________ Service Rep. Name: __________________________________________
Address: _________________________________________________________ Phone #: _________________________
T2KHK3F12D
12 Door Kit with PTC Outputs
Fully assembled kit includes:
- Trove2 enclosure with TKH2 Altronix/Kantech backplane
- One (1) eFlow6NB - Power Supply/Charger
- One (1) T1618300K - Transformer
- One (1) ACM4CB - PTC Access Power Controller
- One (1) ACM8CB - PTC Access Power Controller
T2KHK7F12D
12 Door Kit with PTC Outputs
Fully assembled kit includes:
- Trove2 enclosure with TKH2 Altronix/Kantech backplane
- One (1) eFlow104NB - Power Supply/Charger
- One (1) ACM4CB - PTC Access Power Controller
- One (1) ACM8CB - PTC Access Power Controller
More than just power.™
