INSTRUCTION MANUAL
125LB (56.8kgs)
PUSH SALT SPREADER
Model No: THSSALT -- Product No: 1938134001
DO NOT USE WITH ROCK SALT.
Using rock salt in this spreader will damage the mechanism and shorten the life of the product.
Refined ice melting salt can be used, but the user should be aware that using salt may corrode
certain components of the spreader and reduce the life of the machine.
Clean the spreader thoroughly after using refined de-icing salt.
ASSEMBLY REQUIRED
SAVE THESE INSTRUCTIONS
SPARES & SUPPORT: 01793 333212
Please read & understand this manual, paying attention to the safety instructions, before use.
The manufacturer reserves the right to change the product specification and livery according to
continued product improvements.
Images used are for illustration purposes only
01/02/2018
Advertisement
Table of Contents
Related Manuals for The Handy THSSALT
Summary of Contents for The Handy THSSALT
- Page 1 INSTRUCTION MANUAL 125LB (56.8kgs) PUSH SALT SPREADER Model No: THSSALT -- Product No: 1938134001 DO NOT USE WITH ROCK SALT. Using rock salt in this spreader will damage the mechanism and shorten the life of the product. Refined ice melting salt can be used, but the user should be aware that using salt may corrode certain components of the spreader and reduce the life of the machine.
-
Page 3: Table Of Contents
CONTENTS SPECIFICATIONS IMPORTANT INFORMATION GENERAL SAFETY INSTRUCTIONS KNOW YOUR MACHINE COMPONENTS ASSEMBLY ADJUSTMENTS OPERATION RATE SETTINGS MAINTENANCE PARTS DIAGRAM & LIST WARRANTY NOTES ASSEMBLY IS REQUIRED This product requires assembly before use. See the “Assembly” section for instructions. Please check that all parts required for the assembly of this spreader are included. If for any reason, you believe a part for the assembly is missing or damaged, please contact us. -
Page 4: Specifications
SPECIFICATIONS The manufacturer reserves the right to change the product specification and livery according to continued product improvements. Model THSSALT Product Number 1938134001 Capacity (Weight) 56.8kg (125lb) Hopper Dimensions (cm) 74.9 x 41.9 x 34 Overall Dimensions (cm) 109.9 x 80 x 96.5 Product Weight (kgs) 18.5... - Page 5 DO NOT OVERREACH OPERATION SPEED Keep proper footing and balance at all times Do not exceed 10mph, to avoid personal when using the machine. Never stand on the injury and/or equipment damage. machine. Serious injury could occur if the TYRE INFLATION machine is tipped or if the moving parts are Before operating, make sure the tyres have unintentionally contacted.
-
Page 6: Know Your Machine
KNOW YOUR MACHINE Read this owner’s manual before operating the equipment. Familiarise yourself with the location and function of the controls and features. Save this manual for future reference . 1. T-Handle – Pushes and moves the spreader easily. 2. Flow Control – Controls the flow of material being spread 3. -
Page 7: Components
COMPONENTS NOTE: Parts Lists are supplied for information purposes only, not all parts are stocked individually & we recommend you contact our Spares Team on 01793 333212 for expert advice. -
Page 8: Assembly
ASSEMBLY RECOMMENDED TOOLS REQUIRED • Pliers • Adjustable Spanner • 10mm Wrench x2 • 13mm Wrench STEP 1 - Wheels • When assembling the wheels make sure the air valves are facing outward. • Slide the wheel bushing (#19) onto the left side of the axle. •... - Page 9 STEP 2 – Attach Handle to Support Leg • Insert handle assembly into the supporting leg (#39). In the center holes put two M6x35 bolts (#40), Ø6 spring washer (#55) and secure with M6 lock nut (#9). • On the outer holes of the handle assembly and supporting leg (#39) put four M6x20 bolts (#47), Ø6 spring washers (#55) and secure with M6 lock nuts (#9).
-
Page 10: Adjustments
STEP 3 – Connecting Linkage • Push the flow control handle to the “30” position. Insert the A end of the connecting rod (#34) through the Ø8 flat washer (#12) and into the hole on the gauge level plate (#46). Secure with a M8 lock nut (#11). -
Page 11: Operation
OPERATION DANGER The product must only be put into operation if no defects are found. It is crucial that any defective parts are replaced before the product is used again. Check the safety equipment and the safe condition of the product. Check all parts to make sure that they fit tightly. Check whether there are any visible defects: broken parts, cracks, etc. -
Page 12: Rate Settings
RATE SETTINGS Our spreaders are designed to spread dry, powdered or granulated materials thinly and evenly over reasonably smooth surfaces. • Ensure that the material is dry and free-running. If in doubt pass it through a sieve with 3mm mesh to remove lumps. •... -
Page 13: Maintenance
MAINTENANCE LUBRICATE Maintenance spray or multi-purpose grease can be applied to the wheel axle prior to long-term storage. Oiling is not necessary. GEARBOX Apply multi-purpose grease to the gearbox cogs at the end of each use. CHECK TYRE INFLATION Prior to using the Spreader, ensure the tyres are sufficiently inflated. We recommend the use of FOOT or HAND manual inflation devices only. - Page 14 PARTS DIAGRAM – THSSALT (1938134001) NOTE: Parts Lists are supplied for information purposes only, not all parts are stocked individually & we recommend you contact our Spares Team on 01793 333212 for expert advice.
- Page 15 PARTS LIST – THSSALT (1938134001) NOTE: Parts Lists are supplied for information purposes only, not all parts are stocked individually & we recommend you contact our Spares Team on 01793 333212 for expert advice.
- Page 16 GJ Handy & Co Ltd and agree to only use genuine parts and follow our repair procedures. Webb Electric Handheld, Webb Dynamic, The Handy, Mowerland, Q-Garden a) 1 year from the original date of sale to the first domestic user.
- Page 17 GJ HANDY & CO LTD USER WARRANTY POLICY Not covered by this warranty a) The warranty policy does not cover any depreciation or damages caused by ordinary wear, rusting or corrosion, lack of correct maintenance or operation, misuse, abuse, lack of transportation or accident.
-
Page 18: Notes
NOTES _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________... -
Page 20: Tel: 01793 333212
For spares or support of your handy product, please contact us: Tel: 01793 333212 Email: customerservice@handydistribution.co.uk (Mon – Fri 8.00am to 5.30pm excl. Bank Holidays) To see our range of garden machinery & equipment visit: www.thehandy.co.uk Making gardening easier & affordable since 1938 Distributed by Handy Distribution, Murdock Road, Dorcan, Swindon, SN3 5HY...
