INSTRUCTION MANUAL
50LB PUSH SPREADER
MODEL NO: THS50 -- PRODUCT NO: 193848002
EN - ORIGINAL INSTRUCTIONS
SPARES & SUPPORT: 01793 333212
DO NOT USE WITH ROCK SALT
Using rock salt in this spreader will damage the mechanism and shorten the life of the product. Refined
ice melting salt can be used but the user should be aware that this is not a specialised salt spreader and
using salt may corrode the spreader and reduce the life of the machine. Clean the spreader thoroughly
Please read & understand this manual, paying attention to the safety instructions, before use.
Incorrect use of the product could put the operator or machine in danger.
Whilst every effort has been made to ensure the accuracy of information contained in this manual, our
policy of continuous improvement determines the right to make modifications without prior warning.
ASSEMBLY REQUIRED
SAVE THESE INSTRUCTIONS
after using refined de-icing salt
FOR YOUR SAFETY
Images used are for illustration purposes only
V3 03-04-2019

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the THS50 and is the answer not in the manual?

Questions and answers

Related Manuals for The Handy THS50

Summary of Contents for The Handy THS50

  • Page 1 INSTRUCTION MANUAL 50LB PUSH SPREADER MODEL NO: THS50 -- PRODUCT NO: 193848002 EN - ORIGINAL INSTRUCTIONS ASSEMBLY REQUIRED SAVE THESE INSTRUCTIONS SPARES & SUPPORT: 01793 333212 DO NOT USE WITH ROCK SALT Using rock salt in this spreader will damage the mechanism and shorten the life of the product. Refined ice melting salt can be used but the user should be aware that this is not a specialised salt spreader and using salt may corrode the spreader and reduce the life of the machine.
  • Page 2 Copyright Notice Copyright © Handy Distribution Permission is granted to reproduce this publication for personal & educational use only. Commercial copying, redistribution, hiring or lending is prohibited. No part of this publication may be stored in a retrieval system or transmitted in any other form or means without written permission from Handy Distribution.

  • Page 3: Table Of Contents

    CONTENTS SPECIFICATION IMPORTANT INFORMATION GENERAL SAFETY INSTRUCTIONS COMPONENTS ASSEMBLY OPERATION RATE SETTINGS MAINTENANCE PARTS DIAGRAM PARTS LIST WARRANTY ASSEMBLY IS REQUIRED This product requires assembly before use. See the “Assembly” section for instructions. Please check that all parts required for the assembly of this spreader are included. If for any reason you believe a part for the assembly is missing or damaged, please contact us.

  • Page 4: Specification

    SPECIFICATIONS The manufacturer reserves the right to change the product specification and livery according to continued product improvements. Model THS50 Product Number 193848002 Weight 10.3kg Capacity (Weight) 23kg Wheel Diameter 176mm Tyre Pneumatic - 4.10/3.50-6 Tyre Rating 2 Ply Tyre Maximum PSI...
  • Page 5 DRESS PROPERLY Do not wear loose clothing, gloves, scarfs, neckties or jewellery (rings, wrist watches), which can be caught in moving parts. DO NOT OVERREACH Keep proper footing and balance at all times when using the machine. Never stand on the machine. Serious injury could occur if the machine is tipped or if the moving parts are unintentionally contacted.

  • Page 6: Components

    COMPONENTS FIXING KIT FRAMEWORK NOTE: Parts Lists are supplied for information purposes only, not all parts are stocked individually & we recommend you contact our Spares Team on 01793 333212 for expert advice.

  • Page 7: Assembly

    ASSEMBLY (NUMBERS IN BRACKETS RELATE TO ITEM NUMBERS FROM PARTS LIST, LOCATED AT REAR OF MANUAL) DO NOT FULLY TIGHTEN EACH NUT AND BOLT UNTIL AFTER STEP 6, UNLESS ADVISED IN STEPS. THIS ALLOWS MOVEMENT AND TOLERANCES WHEN ASSEMBLING. STEP 1 •...
  • Page 8 STEP 2 • Install the Impeller (42) onto the spindle of the Gearbox Assembly (39). • Align the Impeller with the hole on the axle, located nearest the gearbox. • Insert 1x M4x20 Screw (41), through the side of the Impeller & Gearbox Spindle. •...
  • Page 9 STEP 3 • Install the Wheel Assembly Frame (20) (with outer bushing) on each side of the gearbox axle, ensuring the axle fixing hole is located as imaged below and FRONT printed on the gearbox casing is to the front of the machine.
  • Page 10 STEP 4 • Install the end of each Frame Brace (31) onto the Hopper Frame (30) using M6x35 Hex Bolt (33) & M6 Lock Nut (24). • Push a M6x35 Bolt (33) through the first hole above the axle right hand Wheel Assembly Frame (20). Pass the bolt through the Frame Brace (31) and into the end of the Cross Brace (45).
  • Page 11 STEP 5 • Slide the Inner Axle Bushing (37) onto the right side of the axle, pushing the Inner Axle Bushing into the Outer Axle Bushing until tight. • Starting with the right side, slide a Nylon Washer (52) onto the axle, attach the Wheel (36) to the axle and fix with a M5x45 Hex Bolt (47) &...
  • Page 12 STEP 6 • Attach the Handle Shaft (26) between the top ends of the Wheel Assembly Frames (20). Pass two M6x45 Bolts (11) through the Wheel Assembly Frames & Handle Shaft. Install the Pivot & Bracket Assembly (19) onto the protruding bolt ends. Fasten with M6 Lock Nuts (24). •...
  • Page 13 STEP 7 • Insert M6x45 Bolts (11) through the Upper Left Handle (23), then through the Handle Spacer (1) and Upper Handle on the right side, fasten with Flat Washer Ø6 (48) & Lock Nut M6 (24). Slide the Gauge and Lever Assembly (4) onto the bolts and fasten with Lock Nut M6 (24).
  • Page 14 STEP 8 • Push the Adjustable Handle (6 & 7) to the lowest position. • Insert the upper end of the Control Rod (25) into the hole at the end of the Adjustable Handle (6&7). • Take Lower Nut (21) off the bottom end of the Control Rod (25) and insert rod into the hole in the Pivot and Bracket Assembly (19).
  • Page 15 STEP 9 Slip the threaded end of Adjustable Connecting Rod (46) into the Shut Off Plate (27) with a Flat Washer Ø6 (48), then fasten with Flat Washer Ø6 (48) & Lock Nut M6 (24).
  • Page 16 STEP 10 • The three large holes at the bottom of the hopper should match the three holes in the adjustable plate. If they match, do nothing. • If they do not match, push the handle down to the lowest position and adjust the positions of the two nuts on the threaded control bar until the three holes match up.

  • Page 17: Operation

    OPERATION DANGER The product must only be put into operation if no defects are found. It is crucial that any defective parts are replaced before the product is used again. Check the safety equipment and the safe condition of the product: Check all parts to make sure that they fit tightly.

  • Page 18: Rate Settings

    RATE SETTINGS Our spreaders are designed to spread dry, powdered or granulated materials thinly and evenly over reasonably smooth surfaces. Due to the many hundreds of different materials which can be used with this spreader, it is impossible to list them all and the relevant spreader setting for the material. We therefore recommend that you test the spread pattern on a hard surface (driveway etc), before passing over the area to be treated.
  • Page 19 MAINTENANCE LUBRICATE Maintenance spray or multi-purpose grease can be applied to the wheel axle prior to long-term storage. Oiling is not necessary. GEARBOX DO NOT open the gearbox. The gears are permanently lubricated from the factory and do not need lubricating. CHECK TYRE INFLATION Prior to using the spreader, ensure the tyres are sufficiently inflated.
  • Page 20 NOTE: Parts Lists are supplied for information PARTS DIAGRAM – THS50 (193848002) purposes only, not all parts are stocked individually & we recommend you contact our Spares Team on 01793 333212 for expert advice...
  • Page 21 PARTS LIST – THS50 (193848002) ITEM PART ITEM PART DESCRIPTION DESCRIPTION TH137-1 Handle Spacer TH137-27 Shut off plate TH137-2 Bolt M6x25 TH137-28 Big Flat Washer Ø4 TH137-3 Lock Washer 08 TH137-29 Screw ST4.2x12 TH137-4 Gauge Plate TH137-30 Hopper Frame TH137-5...
  • Page 22 GJ HANDY & CO LTD USER WARRANTY POLICY Users Statement of Warranty Each new machine is warranted against defective material or assembly of material under normal usage. The warranty applies to the original purchaser and covers faulty parts and the labour involved in replacing and repairing those parts, which are of original manufacture.
  • Page 23 Disclaimer a) This warranty is only a remedy for defect of products. GJ Handy & Co Ltd will never warranty in terms of the merchantability or the fitness for a particular purpose. b) No person is authorised to make any warranties, representations or promises, expressed or implied, on behalf of GJ Handy &...
  • Page 24 For spares or support of your handy product, please contact us: Tel: 01793 333212 Email: customerservice@handydistribution.co.uk (Mon – Fri 8.00am to 5.30pm excl. Bank Holidays) To see our range of garden machinery & equipment visit: www.thehandy.co.uk Making gardening easier & affordable since 1938 Distributed by Handy Distribution, Murdock Road, Dorcan, Swindon, SN3 5HY...
